1.4841, 314, Heat Resisting Austenitic Steel

1.4841, 314, Heat Resisting Austenitic Steel

1.4501 X2CrNiMoCuWN25-7-4 Austenitic-ferritic Stainless Steel

1.4841, also known as AISI 314, is a heat-resistant austenitic stainless steel. It is designed to excel in high-temperature applications, particularly those involving oxidation and scaling resistance. AISI 314 is known for its ability to maintain its mechanical properties at elevated temperatures, making it suitable for use in furnace components, heat exchangers, and other applications where exposure to extreme heat is common. It exhibits good resistance to oxidation and carburization, ensuring long-lasting performance in high-temperature environments. The austenitic microstructure of AISI 314 further contributes to its excellent high-temperature strength and creep resistance.



Our Supply

Smelting line: VIM,VAR, IM, ESR, PESR, LF, VD, AOD

Danieli roll line: round & flat diameter 150mm max

Forged line: 800mm max

Heat-treatment line: annealed, quenched tempered, solution

Machining line: Turning, Milling, CNC

Chemical Composition



BS EN AISI/ASTM C Si Mn max P max S max Cr Ni N
1.4841 314 max 0.2 1.5-2.5 max 2.0 0.045 0.015 24-26 19-22 max 0.11



Mechanical Properties

BS EN AISI/ASTM Heat condition Hardness HB max Proof strength Rp1.0 N/mm2 min. Tensile strength Elongation A% min. long products
1.4841 314 +AT solution annealed 223 270 550-750 30





Our advantage of heat resisting steel

  • High creep limit and lasting strength;
  • Easy smelting and processing and good casting, forging and welding properties;
  • high oxidation resistance and corrosion resistance;
  • high high-temperature mechanical properties;
  • Small expansion coefficient and good thermal conductivity;
  • Good processability and economy.
  • Organization stability at high temperature
  • Low cost

What is heat resisting steel?

Heat resisting steel is a kind of special steel that can maintain good mechanical properties and antioxidant properties under high temperature environment. It has high temperature stability, oxidation resistance and creep resistance, can maintain high strength and hardness at high temperatures, not easy to soften and deformation.



Why choose heat resisting steel?

1. High-temperature stability:

heat resisting steel at high temperatures to maintain high strength and hardness, will not occur obvious softening and deformation.



2. Antioxidant properties:

heat resisting steel surface to form a dense layer of oxide film, can effectively prevent oxidation reaction, slow down the oxidation rate of the material.



3. Creep resistance:

heat resisting steel at high temperatures can resist plastic deformation and creep phenomenon, to maintain good shape stability and dimensional accuracy.



4. Good processing performance:

heat resisting steel has good plasticity and weldability, can be convenient for hot processing and welding.





Application of heat resisting steel

heat resisting steel is widely used in aerospace, energy, chemical industry and other fields, mainly including the following aspects:

1. Aerospace field:

heat resisting steel used in the manufacture of aero-engine turbine blades, turbine discs, combustion chambers and other components, as well as aerospace spacecraft insulation materials.



2. Energy field:

heat resisting steel used in the manufacture of thermal power plant boiler supercritical and ultra-supercritical boiler piping and heating surface, and nuclear power plant nuclear reactor pressure vessel and fuel components.



3. Chemical industry:

heat resisting steel is used in the manufacture of chemical equipment reactor, separator, oil cracker pipeline, etc., which can withstand high temperature, high pressure and corrosive media.



4. Other fields:

heat resisting steel is also widely used in metallurgy, machinery, automobile and other fields, used in the manufacture of a variety of parts and tools under high-temperature working environment.
