BS 6744 Grade 1.4362 Stainless Steel Rebar
Balanced Duplex Performance for Long-Life Chloride Protection
As a leading global manufacturer and exporter, Hunan Fushun Metal Co., Ltd. presents our high-performance duplex stainless steel reinforcing bars, manufactured to meet the stringent requirements of BS 6744. Our Grade 1.4362 rebar provides an optimal balance of high mechanical strength, excellent corrosion resistance, and good weldability, making it a versatile choice for reinforced concrete structures exposed to severe chloride ingress. When your project demands both structural efficiency and decades of maintenance-free service, FUSHUN METAL delivers the right alloy solution.
With deep expertise across specialty steel products, including alloy steel, nickel-based alloys, and tool steel, and full compliance with international benchmarks like ASTM, EN, DIN, and JIS, we guarantee that our BS 6744-compliant reinforcement bars offer unparalleled quality and performance. This introduction focuses on our ribbed stainless steel bar, steel designation 1.4362, in strength grade 500.
Product Image
Technical Specifications & Compliance
Our reinforcement bars are produced and tested strictly in accordance with BS 6744, which specifies the requirements for solid stainless steel bars used for concrete reinforcement. This standard is applicable to ribbed bars in grade 500, where ribs are formed by cold working or hot rolling processes. FUSHUN METAL’s Grade 1.4362 bar is fully traceable with a documented metallurgical history, a critical requirement of the standard.
1. Chemical Composition (Cast Analysis)
The chemical makeup of our 1.4362 rebar is engineered to deliver a robust combination of strength, ductility, and chloride resistance. It is classified under the BS EN 10088 system and, according to BS 6744 Table 5, it is an “austenitic-ferritic (Duplex)” alloy listed within the group used for corrosion resistance to chloride ingress in concrete. The precise cast analysis is tightly controlled within the following limits:
| Element | Requirement (% by mass, max unless range given) |
|---|---|
| Carbon (C) | 0.03 |
| Silicon (Si) | 1.0 |
| Manganese (Mn) | 2.0 |
| Sulphur (S) | 0.015 |
| Chromium (Cr) | 22.0 – 24.5 |
| Nickel (Ni) | 3.5 – 5.5 |
| Molybdenum (Mo) | 0.10 – 0.60 |
| Copper (Cu) | 0.10 – 0.60 |
| Phosphorus (P) | 0.035 |
| Nitrogen (N) | 0.05 – 0.20 |
Note: This composition is in strict adherence to BS 6744, Table 5 for the 1.4362 designation. The well-balanced chromium, nickel, and molybdenum content offers a dependable level of corrosion resistance with good structural properties, making it a proven choice for a wide range of chloride-exposed applications.
2. Heat Treatment Condition
Our ribbed stainless steel bars are supplied in one of the following conditions as per BS 6744, Clause 11, ensuring optimal mechanical properties and surface finish:
- Hot rolled and descaled
- Hot rolled, descaled, and decooled
Per BS 6744, Clause 12.12.1, the 1.4362 duplex grade undergoes additional testing to verify the absence of detrimental metallurgical phases in the finished condition. The results are quoted directly on the test certificate, ensuring microstructural integrity and long-term performance reliability.
3. Dimensions, Mass, and Tolerances
We manufacture the Grade 1.4362 rebar in a wide range of standard diameters, from 6 mm to 50 mm, in full compliance with the standard. The dimensional characteristics are precisely controlled to ensure a perfect mechanical bond with concrete.
Standard Diameters
The following nominal diameters are available as standard for the 500 strength grade, as specified in BS 6744, Clause 5 and Table 2:
| Grade | Nominal Diameters (mm) |
|---|---|
| 500 | 6, 7, 8, 10, 12, 14, 16, 20, 25, 32, 40, 50 |
Note: Non-standard diameters may also be available upon request.
- Nominal Length
- Agreed upon at the time of order, with a standard permissible deviation of +100/0 mm or as per BS 8666.
- Nominal Mass per Meter Run
- Calculated according to BS EN ISO 15630, our bars strictly conform to the specified nominal mass per meter for austenitic-ferritic (duplex) steels. For example, a 20 mm bar has a nominal mass of 2.451 kg/m.
- Tolerances on Mass
- Stringent tolerances are applied, ranging from ±9.0% for a 6 mm bar to ±4.5% for bars over 12 mm in diameter.
4. Grade & Mechanical Properties (Strength Level 500, Ductility Class B)
Our reinforcing bars are designated as strength grade 500 and consistently achieve the mechanical properties for Ductility Class B as defined in BS 6744, Table 8.
| Property | Requirement |
|---|---|
| Designation | BS 6744 – 1.4362, B500B |
| Characteristic Yield Strength (fyk) | 500 MPa |
| 0.2% Proof Strength (Rp0.2) | 500 MPa minimum |
| Tensile Strength (Rm) | Meets the minimum value for the stress ratio |
| Stress Ratio (Rm/Rp0.2) | ≥ 1.08 |
| Total Elongation at Max Force (Agt) | ≥ 5.0% |
| Elongation After Fracture (A5) | ≥ 14% |
| Bendability | Passes 180° bend test around a former of max diameter specified (e.g., 4d for d≤16 mm, 7d for d>16 mm) |
| Fatigue Strength | Withstands 5 × 106 cycles of stress at a stress ratio of 0.2 without fracture, ensuring excellent dynamic load performance |
The duplex microstructure of 1.4362 provides a high strength-to-yield ratio and outstanding elongation, offering designers confidence in both ultimate and serviceability limit states.
Ready to specify BS 6744 Grade 1.4362 duplex stainless steel rebar for long-life chloride protection?
Request a Quote5. Surface Geometry & Bonding
Ensuring a strong mechanical interlock with concrete is paramount. Our bars feature rows of crescent-shaped transverse ribs that meet the geometric criteria of BS 6744, Clause 10:
- Relative Rib Area (fR): Exceeds the minimum relative rib area (fRmin) specified in Table 6, which is the ruling criterion for bond performance.
- Rib Flank Inclination (α): Measured at ≥ 45°, ensuring effective load transfer without splitting the concrete cover.
- Transverse Rib Projection: Extends over at least 80% of the bar’s periphery.
These geometric properties are measured and verified in accordance with BS EN ISO 15630-1.
6. Packaging and Product Identification
Every product from FUSHUN METAL is meticulously packaged and labelled to guarantee complete traceability and compliance.
- Product Marking
- Each bar is identified by rolled-on legible marks on the surface at intervals not greater than 1.5 meters, identifying the manufacturer as specified by the standard.
- Bundle / Coil Labelling
- Each bundle or coil is firmly attached with a durable label containing all the mandatory information per BS 6744, Clause 13.2:
- Standard Reference (BS 6744)
- Steel Designation (1.4362)
- Nominal Diameter
- Strength Grade (500)
- Ductility Class (B)
- Durability Class
- Cast Number and Batch Reference
- Manufacturer’s Name (FUSHUN METAL)
7. Inspection & Test Report
Quality assurance is non-negotiable. Our products are tested at a frequency of one test per ten tonnes from each production batch. Every shipment is accompanied by a detailed test certificate as per Clause 12.3, which includes:
- The complete cast analysis for all specified elements.
- Results of the tensile test (including effective cross-sectional area), confirming 0.2% proof strength, stress ratio, and elongation properties.
- Results of the bend test.
- Charpy impact test results (three tests per batch, for diameters 16 mm and above), in accordance with BS EN ISO 148-1.
- Intergranular corrosion test results (one test per batch), in accordance with BS EN ISO 3651-2, confirming the absence of detrimental phases.
- Confirmation of durability class and the manufacturer’s rolled-on mark.
- A statement of conformity to BS 6744.
Frequently Asked Questions
How does Grade 1.4362 compare to other duplex grades like 1.4162?
Both are low alloy duplex stainless steels listed in BS 6744 Table 5 for corrosion resistance to chloride ingress. The 1.4362 grade features a higher chromium (22.0–24.5%) and nickel (3.5–5.5%) content compared to 1.4162, along with a lower nitrogen range. This chemistry provides an enhanced level of corrosion resistance while still maintaining a very high strength. It is an excellent choice when the project requires a step above the leanest duplex in terms of chemical resistance, but without moving to a highly alloyed super-duplex.
Is 1.4362 rebar magnetic?
Yes. As a duplex stainless steel with a mixed austenitic-ferritic microstructure, 1.4362 is ferromagnetic. This is in contrast to standard austenitic grades like 1.4301 and 1.4311, which have very low magnetic permeability. Guidance on magnetic properties is provided in BS 6744 Annex C. This magnetic characteristic can be a practical advantage on-site for handling and separation.
What supplementary tests are mandatory for this duplex grade?
Per BS 6744, Clause 12.12, all duplex designations, including 1.4362, require additional testing beyond standard tensile and bend tests. For every batch, we perform the Charpy V-notch impact test on bars 16 mm and above (per BS EN ISO 148-1) and an intergranular corrosion test (per BS EN ISO 3651-2). These tests are mandatory to confirm the material is free from detrimental phases that could impair toughness or corrosion resistance, and their results are listed on the inspection certificate.
What are the most common applications for 1.4362 concrete reinforcement?
This alloy is widely specified for infrastructural and marine applications where a high level of chloride resistance is required to eliminate costly maintenance. Typical uses include bridge decks and support structures in coastal or cold climates (exposed to de-icing salts), sea water intake structures, quay walls, and foundations for chemical or water treatment plants. It is selected for structures with a design life of 100 years or more where proven duplex performance is needed.
Can FUSHUN METAL supply 1.4362 reinforcement fabricated to BS 8666?
Yes, absolutely. Per BS 6744, Clause 11, our ribbed stainless steel bars can be supplied straight, in coils, or fabricated in accordance with BS 8666 (“Scheduling, dimensioning, bending and cutting of steel reinforcement for concrete”). We can deliver complex prefabricated cages and bent shapes directly to your site, ensuring dimensional accuracy and minimizing on-site labor, while maintaining full traceability for every component.
Build with Confidence Using 1.4362 Duplex Reinforcement
Contact FUSHUN METAL today to learn how our BS 6744 Grade 1.4362 duplex stainless steel reinforcement can provide a reliable, corrosion-resistant foundation for your next major infrastructure project.
